Fully Automatic Closed Cup Flash Point Tester, used for determining the closed cup flash point of petroleum products. It adopts advanced foreign technology, with a liquid crystal TFT full-color touch screen, and a full Chinese display human-machine dialogue interface. For pre-set temperatures, oil sample numbers, atmospheric pressure, test dates, and other parameters, it features a prompt menu input method, making it convenient and fast. The open-type, fuzzy control integrated software and modular structure comply with GB/T261-2008 and GB/T261-83 standards. It is an ideal alternative to imported instruments. Widely used in railway, aviation, power, petroleum industries, and research departments.

1. It features a Chinese software prompt for incorrect operations and modification;
2. It provides parameter prompts for test date, test time, etc.;
3. Automatically corrects the effect of atmospheric pressure on the test and calculates the correction value;
4. Differential detection, with automatic correction of system bias;
5. Opening the lid, ignition, detection, and printing of data are automatically completed;
6. The test arm is automatically raised and lowered;
7. Ignition method: electronic ignition.

1. Temperature Measurement: 50～200℃
   Repeatability: ≤2℃
   Reproducibility: ≤±4℃
   Resolution: 0.1℃
   Accuracy: 0.5%

2. Ambient Temperature: 10-40℃
   Relative Humidity: ≤85%
   Supply Voltage: AC220V 50Hz±5%

3. Basic Parameters
   Heating Rate: Complies with GB/T261-83 and GB/T261-2008 standards
   Ignition Method: Electronic ignition
   Power Consumption: Less than 300W
