Applications:

The KDWS-B SF6 Intelligent Moisture Tester is a modern, high-level, intelligent measuring instrument newly developed by our company. This instrument is applicable in a wide range of fields, suitable for measuring the humidity of air, nitrogen, inert gases, and any gases without corrosive media. It is especially appropriate for measuring the humidity of SF6 gas. Departments such as power, petrochemicals, metallurgy, environmental protection, and research institutes can all use it, offering an excellent cost-performance ratio.

  • Response within
    24 hours

  • Free warranty
    12 month

  • On-line training
    Support

Profile:

The KDWS-B SF6 Intelligent Moisture Tester is a modern, high-level, intelligent measuring instrument newly developed by our company. This instrument is applicable in a wide range of fields, suitable for measuring the humidity of air, nitrogen, inert gases, and any gases without corrosive media. It is especially appropriate for measuring the humidity of SF6 gas. Departments such as power, petrochemicals, metallurgy, environmental protection, and research institutes can all use it, offering an excellent cost-performance ratio.

Features:

1. Portable design. The instrument is lighter, making it convenient to carry and use.

2. Rapid and gas-saving. No preheating is required after startup, quickly reaching the dew point saturation state. During measurement, it consumes only about 2L (at 101.2kPa) of gas.

3. Safe and reliable. Uses German original imported self-locking connectors, ensuring safety and reliability without gas leakage.

4. Massive storage. Features a large capacity design, capable of storing up to 50 sets of test data.

5. Intuitive display. The LCD screen directly shows the dew point, moisture content, ambient temperature, ambient humidity, time and date, battery level, etc.

6. Mobile measurement. Equipped with a high-capacity built-in lithium battery, allowing for continuous operation for up to 10 hours on a full charge.

7. Accurate measurements. Includes a temperature compensation function to ensure measurement accuracy under various temperature conditions.

Parameter:

Dew Point Measurement Range -60℃ to +20℃
Measurement Accuracy ±2℃ (-60℃ to +20℃)
Measurement Time <3 minutes
Ambient Temperature -40℃ to +60℃
Ambient Humidity 0~100% RH
Power Supply AC 220V / Built-in rechargeable battery:
charges for 20 hours, can be used for over 10 hours

Weight 3 kg
Dimensions 250 mm × 100 mm × 300 mm
Operating Temperature -40℃ to +80℃
